| WORKSTATÄ°ON | |
|---|---|
| IMAGE PREVÄ°EW | Less than 2sec |
| DETECTOR | DÄ°GÄ°TAL RADÄ°OGRAPHY SYSTEM AERODR |
|---|---|
| SCÄ°NTÄ°LLATOR | CsI (Cesium Iodide) |
| PÄ°XEL SÄ°ZE | 175μm |
| IMAGE FÄ°ELD | 1,994×2,430 (4.8 million pixels) |
| DÄ°MENSÄ°ONS(W X D X H) | 383.7×460.2×15.9mm ※Equivalent to Standard 14×17″ cassette |
| DYNAMÄ°C RANGE | 4 digits |
| GENERATOR | |||
|---|---|---|---|
| OUTPUT | 50kW | 65kW | 80kW |
| FREQUENCY(UP TO) | 240kHz | 240kHz | 240kHz |
| EXPOSURE VOLTAGE | 40 to 150kVp | ||
| MA RANGE | 10 to 1000mA (depending on selected kW) | ||
| DUAL SPEED STARTER | Standard | Standard | Standard |
| INPUT RATÄ°NG | 400/480VAC 50/60Hz | ||
| X-RAY TUBE | Varian | ||
| FOCAL SPOT | 0.6/1.2mm | ||
| KHU | 300 (212kJ) | 400 (300kJ) | 600 (445kJ) |
| CEÄ°LÄ°NG SUSPENSÄ°ON | 32/77kW | 40/100kW | 40/100kW |
| ANODE ANGLE | 12° | 12° | 12° |
| ROTATÄ°ON SPEED | 10000rpm | 10000rpm | 10000rpm |
| CEÄ°LÄ°NG SUSPENSÄ°ON | |||
|---|---|---|---|
| WEÄ°GHT | 127kg, standard tube and collimator | ||
| VERTÄ°CAL STROKE | 1450mm or 1700mm | ||
| TUBE ROTATÄ°ON | Alpha from -163 to 180, Beta from -180 to 163 | ||
| MÄ°NÄ°MAL CEÄ°LÄ°NG HEÄ°GHT | 2500mm | ||
| HEÄ°GHT MOVEMENT | Motorized | ||
| TRACKÄ°NG | Height tracking on wall and table | ||
| TABLE (AERODR T50) | |||
|---|---|---|---|
| VERTÄ°CAL STROKE | 540-850mm, floor – table top | ||
| PATÄ°ENT LOAD | Tabletop for 295kg Patient weight, 0.7 mm AL eq | ||
| ATTENUATİON EQUİVALENT | ≦0.7 mm AL eq. | ||
| DÄ°MENSÄ°ONS TABLE TOP | 2400×800mm | ||
| MOVEMENT TABLE TOP | Lateral ±150mm, longitudinal ±500mm | ||
| IMAGE RECEPTOR TRAVEL | ±290mm | ||
| AEC | Three-field ionisation chamber (Optional ) | ||
| NON TÄ°LTÄ°NG TYPE WALL STAND (AERODR S30) | |||
|---|---|---|---|
| VERTÄ°CAL STROKE, DETECTOR Ä°N VERTÄ°CAL POSÄ°TÄ°ON | 310mm-1780mm , floor -center detector | ||
| ATTENUATİON EQUİVALENT | ≦0.6 mm Al eq, | ||
| AEC | Three-field ionisation chamber (Optional ) | ||
| GRÄ°D | Manually exchangeable | ||
| TÄ°LÄ°TÄ°NG TYPE WALL STAND (AERODR S33) | |||
|---|---|---|---|
| VERTÄ°CAL STROKE, DETECTOR Ä°N VERTÄ°CAL POSÄ°TÄ°ON | 310mm-1710mm , floor -center detector | ||
| VERTÄ°CAL STROKE, DETECTOR Ä°N HORÄ°ZONTAL POSÄ°TÄ°ON | 580mm(minimum) , floor – top cover | ||
| POSÄ°TÄ°ONS DETECTOR | 90°- -20° | ||
| ATTENUATİON EQUİVALENT | ≦0.6 mm Al eq, | ||
| AEC | Three-field ionisation chamber (Optional ) | ||
| GRÄ°D | Manually exchangeable | ||
| COLLÄ°MATOR | |||
|---|---|---|---|
| Auto collimator (APR based) , Integrated DAP chamber Integrated Automated filter (APR based) , Laser light | |||
| INSTALLATÄ°ON CUBE | |||
|---|---|---|---|
| 3m×4m,150kg ( including transfers) | |||
